In this video I'm going to be talking to you about cross-cutting wood, and that would be defined as
0:07
cutting wood across the grain. It could be a 90-degree cut or anything over to about 45 degrees. It's all considered
0:14
cross-cutting. There are different ways to cross-cut, but the demonstration I'm going to give you now involves
0:21
something called a mitre gauge. This is the one that came with this saw, and it's a pretty good
0:27
pretty good mitre gauge. You can adjust it for different angles. It swivels over to different angles
0:34
even past 45 in this case. But for this cut, we're going to go out. We're going to do a 90 degree cut
0:41
One thing I do recommend, if possible, is to take your stock
0:46
mitre gauge and add a piece of wood to it like this. That gives a much longer surface area. And in this
0:57
case I've applied some high friction tape the kind you put on a set of stairs to make them
1:02
safer it helps to keep the wood stationary it's just a little bit of a tweak
1:07
and it's helpful but but not necessary another thing you might want to consider
1:13
is an upgraded miter gauge this one as they all do fit into the slot and the table top this comes with a longer support area of course but what I really like about this one is that it got a length stop
1:35
which you can adjust if you want to do repetitive cuts, and you can also flip it out of the way when you're not using it
1:41
So I will be using this miter gauge for this demonstration. Like all miter gauges, an angle setting here
1:51
so you can adjust things. With some of these aftermarket, miter gauges, you have to be careful about something
1:58
because this part can slide back and forth and you don't want it to hit the guard
2:04
or actually to get cut and cut by the blade. So just pay attention to that
2:11
You want it as far over as you can. Now cross cutting can be very safe
2:19
There's one thing you need to be careful of though, and that's
2:23
that the fence be completely out of the way. Now, you might think, well, what would the fence matter
2:34
Well, once you make your cut, and there's a piece has been removed from your main workpiece
2:40
if the fence is too close, the workpiece can get caught between the fence and the blade
2:46
and that almost guarantees a kickback event. So when you cross just move the fence well and truly out of the way Now in this case I got the guard in place I recommend you always have the blade guard in place like this
3:04
It's going to obscure the cut, so we're not really going to see what's going on
3:09
but you will see the results. As with all table saw operations, you really should wear safety glasses
3:17
This saw is not particularly loud, but I make it a habit to
3:21
to wear hearing protection all the time so I recommend the same now before I
3:26
actually do a cut I'm gonna do a kind of a sample test run without the blade
3:31
running just so you can hear what I'm talking about and and hear my
3:35
explanations so I'll just lift the guard up and I'll have the wood slid over
3:41
so it doesn't encounter the blade but essentially this is the procedure you have
3:46
the blade as high as you should have it which For all cuts is really maybe a quarter to a half inch above the workpiece
3:59
Any lower than that and you slightly increase the chance of a kickback event
4:06
Any higher than that and there's more blade exposed so a slightly greater chance that you might run into trouble and hurt yourself
4:14
So quarter inch, half inch above the workpiece, that's pretty standard. If I was actually making the cut right now I would be holding the handle of the miter gauge In one hand I be holding the workpiece with the other I well away from the blade I going to slide it forward make the cut and then move the workpiece back
4:38
There's now an off cut on the other side of the blade, and I'm going to immediately switch off the saw
4:43
and I'm not going to do anything until that blade comes to a complete stop
4:48
That's pretty important. And you don't want to get too eager and get close to the blade while it's still spinning because accidents can happen that way
4:56
So if you follow that advice, you'll be safe. Now, guard in place, safety glasses on, hearing protection
5:12
I have this saw connected to a dust collector, so I'm going to switch that on now
5:19
The And that's how you do a basic crosscut with a mitre gauge
