9 moisture meter in action
3K views
Jan 24, 2024
9 moisture meter in action
View Video Transcript
0:00
So I want to show you something that applies to people who have woodworking
0:05
shops like I do and even people doing home renovations especially when it
0:09
comes to laying hardwood flooring and this is the thing here it's a moisture
0:15
meter and it tells you how wet wood is. This one's fairly old I don't know if
0:20
they make this model anymore but essentially it's just a device for
0:25
measuring electrical resistance and I just got a load of cherry in this
0:30
morning. Cherry is one of my favorite woods and I'm making a stair railing out
0:36
of this stuff. It feels dry enough but is it dry because I don't want to mill this
0:42
wood down to final size until it is completely dry and that dryness is
0:49
expressed in moisture content. You can see the scale here for a heating climate
0:55
like where I live in Canada we want wood to be between seven and nine percent
1:00
moisture and this device or anyone like it takes the guesswork out of that. Now
1:07
before I show you how it works I want to show you this little thing because as I
1:12
said this is a device for measuring the electrical resistance of wood. The
1:17
moisture wood is the less electrical resistance and the higher the the little
1:23
needle goes. So in order for this to be accurate it has to be calibrated and
1:28
that's what this thing here is for battery and calibration check. So when I
1:33
put the two prongs on these two screw heads here and I push the button then
1:41
the meter should read 16%. Let's see. It's perfectly calibrated. If it wasn't I
1:48
could use a small screwdriver in here to turn it and that would move the needle
1:52
while I was pressing it and then I would I would know that I'm right on. So about
1:59
an hour ago these were boards now I'm turning them into stair spindles. This
2:06
was the surface that was close to the board. If you can imagine there were a bunch of these they were they were lined up like this. So this was the
2:14
surface that was closest to the surface of the board. I planed it it used to be
2:18
rough and I planed it and now I've also sliced it into thickness for the
2:23
spindles. So this is a surface that used to be deep into the board right here but
2:29
now it's exposed. That's the sort of surface that I want to examine with the
2:35
moisture meter because if I test it up here it might be superficially dry but there could be quite a bit of moisture deep in the board. So this used to be
2:42
deep in the board until a few minutes ago and let's take a look see what we we have. So I'm gonna stick the prongs in press the button and yeah we're well
2:52
within that seven to nine percent safety range. Now I didn't see where this wood
2:59
was stored. It was picked up for me at a warehouse but I can tell for sure that
3:04
this wood was stored in a heated environment. You can have wood that's
3:10
stored in a sheltered but unheated environment for a hundred years and it's
3:15
never going to get drier than 12 to 14 percent. So the fact that we're down to
3:21
seven to nine shows that this was in a heated space. I can proceed with confidence now. Now this is for furniture and woodworking and things but the same
3:29
applies if you're installing wood flooring. It's not unusual for people to
3:36
come to grief with wood flooring. They put it down they don't realize how damp
3:40
it is and then it shrinks and they get all kinds of cracks between the boards
3:44
and there's really nothing you can do in that case. So the trick, see the moisture
3:49
level of the wood you're using and don't do anything significant with it until
3:54
you're in that seven to nine percent critical level
