A reader of mine named Donald from southern Quebec wrote to me about a
0:05
cathedral ceiling issue they have, he has in their home. There's bat insulation
0:11
fiber insulation in the cathedral ceiling and they've had a lot of trouble
0:15
with it over the years. It doesn't work very well, there's lots of heat gain in
0:20
summer and heat loss in winter and the ice and snow is melting on the
0:25
roof and running down and forming ice dams and there's also condensation
0:29
occurring during cold weather within the cathedral ceiling. Now these are all
0:33
very typical issues when it comes to cathedral ceilings in cold climates. I
0:39
hear about them all the time. Donald's plan for solving the problem is to
0:44
completely remove all the bat insulation and replace it with 10 inches of closed
0:51
cell spray foam and he's wondering if this is a good plan. It is actually a
0:56
very good plan. It's going to solve all of the problems that he's been having
1:00
and even some he probably doesn't realize he has, namely air leakage
1:07
Spray foam insulation is great because it insulates well and it acts as its own
1:13
vapor barrier but it also seals out drafts remarkably well so the plan's
1:19
going to work fine. Donald was wondering about ventilating that space and he had
1:25
some suggestions for how he was going to ventilate this cathedral ceiling but no
1:30
venting is required. When you have completely spray foamed the underside of
1:35
a roof structure, what you have is a sealed roof and it's considered a hot
1:41
roof so it doesn't need ventilation and you really couldn't ventilate it anyway
1:46
It's all going to be sealed up with the foam and then the drywall or tongue and
1:51
groove lumber or whatever he's going to put on the inside. So typical cathedral
1:56
ceiling problem and excellent solution on Daniel's part. Oh and I forgot to
2:02
mention one more thing. When you've got a roof that is unventilated, as in
2:08
Daniel's case, it's going to become very hot in the summertime and that can be a
2:12
problem with regular organic asphalt shingles. They don't like all that heat
2:18
and they will fail prematurely. In five, six, seven years they'll be curled and no
2:22
good. So in Daniel's case he's going with a metal roof which will work fine. The
2:28
metal roof is going to be sitting on strapping that he fastens to the roof structure. If you didn't want a metal roof and you want the look of shingles
2:36
then fiberglass shingles are the way to go. They look just like regular organic
2:43
asphalt shingles and in fact they they are a tar based product. You can't really
2:47
tell them apart from from traditional asphalt shingles. But the difference is
2:52
that the substrate, instead of being a kind of a thick tar paper, the substrate
2:56
is actually fiberglass, non-woven fiberglass. And those can really withstand heat very well. I've used them in some of my own projects on roofs that are hot
3:07
and insulated in a similar way that I'm telling you now. And they look as good
3:13
today as as they were when I put them on 10 years ago. They've got I think it's a
3:18
50-year warranty and they've made a good start on that too. So the only issue with
3:22
the hot roof in a cathedral situation is the roofing. Either metal or fiberglass
3:28
shingles are the way to go
