110VIDEO Cordless Drill Tutorial
14K views
Jan 25, 2024
110VIDEO Cordless Drill Tutorial
View Video Transcript
0:00
In this video I want to talk to you about cordless drills and my goal with this video is first to
0:07
educate you, just give you a little bit of an idea of how they work and what the controls do
0:11
but then also to help you make proper buying decisions. Because as I've mentioned
0:17
I'm convinced that a cordless drill is one of the first power tools you should buy. It's very
0:22
useful and not just for woodworking either. You'll find use for it all around the house
0:27
Many of you might already have a cordless drill, in which case you don't need to buy one
0:32
but you still might want to learn something here. I guess the first thing I want to talk about is
0:37
voltage. The most common voltages now are on the small end 12 volt. A very common voltage
0:48
in the middle is 18 or 20 volts, and then you can get up to some higher voltages too. But
0:54
for your purposes, you just need to look at the 18 or the 20 volt drills. They're actually the
1:01
same voltage. A lot of people, even professionals, are confused about this because DeWalt is the one
1:08
company that sells 20 volt drills, or the mainline company that sells 20 volt stuff
1:15
In North America, in Europe, they're not allowed to call those same tools they call 20 volt here
1:21
they must call 18 volt there. The reason is because of how that voltage is measured
1:28
18 volts is the voltage that the battery pack gives out when the drill is under some arbitrary
1:35
load, when it's actually working. This is an 18 volt drill, but as I've done before, you take the
1:42
battery pack out, you test the voltage. This baby, when it's fully charged, will be more than 20
1:48
volts, even though it's called an 18 volt drill. Same voltage as what you'll get from the DeWalt 20
1:55
volts. So DeWalt makes great stuff, no problem with their stuff. I just want to alert you to
2:00
the fact that when you buy a 20 volt drill, you're not getting, you know, two volts more power or
2:05
runtime or whatever than in an 18. They're the same. So, and an 18 volt, by the way, is gonna
2:13
serve you well. It's a very good general purpose voltage. Do not go with the 12 volts. They're
2:18
great machines, but they're, they're small. They're meant to fit in your tool pouch
2:23
You're not going to get the kind of power you need. So 18 or 20, that's the good all-around
2:28
voltage. This is a Milwaukee drill, professional grade, very durable. I can't remember when I got
2:36
it, but I've had it for a long time. It's fallen off ladders and it's done a whole bunch of stuff
2:41
and it's still working well. A drill like that, I'd have to check the prices, but I mean way over
2:47
$200 probably into the $300 range here in Canada, in Canadian dollars. You probably don't want to
2:55
spend that kind of money on a drill like that because there's a bunch of other things you want
2:58
to buy too, but you don't have to spend that much money to get a good drill. Rule of thumb
3:05
about $100 is about as little as you want to pay for a cordless drill. Right now Craftsman
3:13
has a decent cordless drill. It's a little bit under $100. There are plenty of off-brands
3:21
names you've never heard of before, in the $50 range. So yeah, a cordless drill for $50 with
3:28
charger and battery, it's too cheap. That's one point I want to make. It's very, very easy to
3:34
buy tools, power tools, that are too cheap. And by too cheap, I mean they're not going to last
3:39
So that $50 drill, I mean it could poo out in a year or less, in which case, you know, you're back
3:44
to square one. So you've essentially wasted that money. So better to spend a little bit more to get
3:48
to a decent level, and there's a handful of them that fit into that category. Around $100, a little
3:54
more than $100 will get you some excellent performance. Now one brand I really like
4:02
for in terms of dollars spent and value delivered is Ryobi. They make great stuff
4:10
I wouldn't call it professional grade, but it's very, very good. Very durable, lasts a long time
4:18
In fact, I know a number of professionals that use a lot of Ryobi power tools. And the reason
4:24
is because a fast-paced professional views a tool like this as a kind of a disposable thing
4:32
especially if they have workers. You know, that worker might not really care so much
4:36
might leave it on the ground, it could get run over, could fall off a ladder and break. So Ryobi is a consumer grade line, but it's sufficiently good to work in a professional
4:47
arena. So that's important to know about. All drills have a similar layout
4:54
This control here, it's kind of like the gear shift on a manual car. You put it down there
5:00
that's the number one position. You're going to get maximum torque, so that's twisting force
5:08
but not terribly fast speed. And you shift it into position two, you're going to get much
5:14
faster rotation, but correspondingly less torque, less twisting force. When I'm drilling wood
5:22
it's pretty well always in the fastest setting. This collar here on the outside, that controls
5:29
the clutch. So for instance, if I have this collar all the way over here, that's a drill bit sign
5:37
That means that it's full lock-up power, which means there's going to be no slipping
5:42
I mean, the only way I can stop this is if I actually stall out the motor. And that's what you want for drilling. But let's say you want to drive some screws
5:51
which a drill is okay for, then you can rotate the collar, and depending on where you put it
5:58
the chuck will start to slip at a certain torque level. So you can get screws driven
6:03
more or less to the same depth automatically. I'm not stalling out the motor, but I'm stalling out
6:11
the chuck, so to speak. And the higher I turn this, the more torque is delivered
6:17
before it does that slipping sound. So another thing, batteries. Within a given voltage and a
6:28
given line, like this is 18 volts, that's all fine and dandy, but the voltage bears
6:36
no influence whatsoever on how long this battery is going to last before I have to recharge it
6:43
That feature, that function, is from the amp-hour rating. That's A-H, amp-hour. So
6:52
this battery can put out one and a half amps of current, and it can sustain that for one hour
7:00
As cordless tool batteries go, this is pretty small. I don't think they get any smaller than
7:05
this. And that's often what you get with entry-level tools at Barkin prices, and that's
7:12
smallish batteries. But realize that you can get batteries that are longer. They're deeper
7:18
They have more cells inside, and a higher amp-hour rating. Let's just take a look at this one here
7:27
This one doesn't say. This one doesn't say either. Oh, hang on a sec
7:35
Let me get one that does say something here. Just a sec. This is where I keep all of my
7:39
cordless tool stuff. Ah, yeah. This would be about the smallest size cordless tool battery
7:47
you can find, and this is about the biggest. It doesn't fit on this one, of course, because it's
7:51
a Milwaukee, but 12.0, that's 12 amp-hours. So quite a lot more power packed in it than this one
8:02
And with the bigger batteries, it's amazing. You can work all day. You can drive deck screws all
8:06
morning long, and it won't run out. It really lasts an awfully long time. When you're in the
8:12
market for a drill, you really should keep your eye open for what I call combination kits
8:20
And that's two or more cordless tools put together in a package, and usually at a pretty
8:26
good price too. So if you want to buy a drill, keep your eye out for a kit that might include
8:33
for instance, it could be different things, but might include what's called an impact driver
8:37
which looks kind of like a drill, but is much better suited to driving screws. This is really
8:44
a screw driving tool. A drill can drive screws too, but just not as well. This will be faster
8:51
and the driver tip will stay engaged with the screw head better without rounding out so much
8:57
Now here's some of the other things that you might see as you're shopping around. Of course, here's the Ryobi impact driver. All impact drivers have the
9:09
same sort of look, the same kind of collet on the front for holding the bits. But this particular
9:17
kit came with a right angle drill. Quite handy actually for when you have to sneak in and drill
9:24
in close quarters. And here we have a little grinder actually. It's for grinding metal
9:31
And another thing, this is kind of an up-and-coming thing. This is something like an impact driver
9:38
except as you can see it's got a square shaft on it. This is a 3-8 square shaft that accepts
9:45
sockets from your socket wrench set. So if you have to do some work on the vehicle
9:49
sometime, then a tool like this can help. This won't really, this isn't going to be strong enough
9:54
to take your wheel nuts off or anything like that, but they do make power tools that are strong
9:59
enough to take your wheel nuts off. In fact, in professional circles, mechanics and things like
10:04
that, they're moving away from the air tools. You know, the air wrenches that you use in here
10:11
sort of rat-tat-tat-tat-tat in garages when you go to visit. Those are falling out of favor
10:18
and the cordless equivalents are becoming more popular. That's because you don't have a cord
10:24
it's just handier and at least as fast, if not faster, than the air tools too
10:29
In fact, I know of a professional mechanic, he was working out at a quarry near us, a great big
10:34
quarry, working on huge machines. He had that kind of impact wrench too, the great big ones he was
10:41
using on the big, you know, the earth movers and the big dump trucks. He only had one battery with
10:49
him at the time, as I heard, and it fell off scaffolding and broke. So now he was out of luck
10:55
he didn't have his impact wrench anymore. He just packed up his tools and drove the three hours back
11:00
to his house because he just was not going to work on this equipment without having that kind of
11:04
help. So this whole cordless thing, it's really getting to be a significant player in the whole
11:12
tool business, both for very demanding professionals, but also for you too. When you're
11:19
buying tools, keep your eyes open for the warranty on the batteries. Now the battery warranty period
11:27
is usually different from the tool warranty period, and the reason I mention that is because
11:32
replacement batteries can be expensive. It's easy to spend a hundred dollars on a replacement
11:40
battery. I don't know what each of these individual ones cost, but a big whopper like this could be
11:45
two or three hundred bucks for a battery, and you want to make sure it lasts a long time. So
11:50
the Ryobi line, for instance, has a three-year warranty on the batteries, and that's pretty good
11:55
Rigid, if you buy a rigid cordless drill, say, and you register as an owner of that drill
12:01
you'll enjoy a lifetime warranty on those batteries. It's amazing, especially considering
12:06
that batteries are consumable items. I mean, nobody expects a cordless tool battery to keep on
12:13
performing for 10 years. I mean, they're going to go bad before then, so you have to expect
12:19
to replace them sometimes. The fact that Rigid will keep you supplied with batteries as long
12:26
as you live, as long as you're registered, I think that's a very good deal, and that certainly
12:30
the Rigid line, I've talked to the people behind Rigid, and they position that as a serious
12:37
a serious non-professional user. So it's quite robust. It's a very good line
12:45
Professionals do use it too, but also discerning homeowners as well. So that's the story on
12:52
cordless drills, and when it comes to woodworking, we're going to be using twist bits like this in
12:58
our cordless drill to make holes, and also for bigger holes, one excellent and economical option
13:06
is these spade bits. They don't look like much, but when they're sharp and when they spin fast
13:12
they can actually make excellent holes in wood larger than the twist bits too. So I hope that
13:19
helps you find the kind of cordless drill that makes sense for you
