Owning a generator to provide backup electrical power for your home during an outage is one
0:17
thing, but getting that generator power into your electrical panel safely and legally is another
0:24
There are different hardware options to make this happen, and in this teaching and product
0:28
video, I'll show you one of the simplest, most flexible, and most economical generator
0:34
connection possibilities going, something called a manual transfer switch, or MTS for short
0:41
Besides being far cheaper than the alternative of a standby home generator, a portable generator
0:47
connecting to one of these manual switches offers distinct advantages. The system is more economical and easier to install than a stationary automatic standby
0:56
generator, you don't need to have the utility power to your home disconnected during installation
1:01
as with meter-based connection systems, and you can easily upgrade to a larger portable
1:06
generator in the future if you need it. You can also use your portable generator in other locations when it's not supplying power
1:13
during a blackout, and if your portable breaks down when you really need it, you can simply
1:19
swap in another one until grid power returns. That is an MTS
1:26
It's not difficult to understand how manual transfer switches work. Even though the entire unit is called a switch, the actual switching mechanism is just one
1:35
part of it. The switch itself is housed within a small metal panel box that includes circuit breakers
1:41
that are typically part of the package. So don't be confused by the term manual transfer switch, it applies to the entire unit that
1:48
gets installed in your home. Planning and MTS Installation The planning process for transfer switch installation begins by deciding which circuits you want
1:59
powered by your generator during an outage, and which ones you can do without
2:04
Essential circuits typically include lighting, wall outlets, a furnace or air conditioner
2:09
a water pump if you're on a well, and perhaps internet equipment, a sump pump, or a sewage pump
2:16
Many of these items don't have plug outlets so they can't be connected to a generator
2:20
using an extension cord. Sidestepping this problem is the biggest advantage of a manual transfer switch
2:28
It allows you to deliver power to essential hard-wired items and outlets that can only
2:33
get their power through the electrical panel. It's important to understand that portable generators don't typically put out enough
2:40
power to energize everything in most homes, so one way or the other you'll need to choose
2:45
which circuits to power. Installing a transfer switch just means you make this decision ahead of time, as circuits
2:51
are re-routed into the manual transfer switch panel during installation. Why not just a simple outlet
3:00
It's dangerous and illegal to connect a generator directly to hard-wired circuits in your electrical
3:05
panel without the right kind of switch in place, because of the hazard this poses to
3:10
electrical workers. I often cover generator-related topics on video, and I sometimes hear from people who
3:16
brag about saving time and money making a direct, switch-less connection between generator
3:22
and panel. Don't ever do this. Utility workers have died by electrocution from generator power that they didn't know
3:30
was back-feeding through the power lines they were working on. This is why various transfer switch options were developed
3:37
Ignore this advice and it could lead to big trouble for you and others
3:41
How to install and use an MTS Installing a transfer switch is work for a licensed electrician, but the concept behind
3:50
the product is simple. As a homeowner, you'd be wise to understand what's involved before hiring anyone
3:57
Wires connected to circuit breakers in your existing electrical panel get disconnected
4:02
and re-routed to different breakers within the transfer switch panel itself, typically
4:07
located nearby. These new connections involve short lengths of cable extending to the transfer switch
4:14
with twist-on wire nuts securing the connections to existing household wiring within your electrical panel
4:22
A weatherproof outlet comes with most transfer switch kits, including the Champion unit I
4:27
have at my place, and gets installed on the outside of an exterior wall to allow easy
4:32
connection of the generator. When grid power goes down, you need to do two things
4:38
One, connect your generator to the weatherproof outlet using the special power cord provided
4:43
with the unit, then get the generator running. Two, flip on the manual transfer switch inside your home to disconnect the panel from the grid
4:54
This simultaneously establishes a direct connection between your generator and those essential
4:59
circuits you had re-routed into the transfer switch panel, all with a guaranteed disconnection
5:05
from the grid. Both functions are handled by the same two-position toggle switch
5:10
For safety, fuel power generators must always be used outdoors, far from occupied buildings
5:16
with the exhaust pointed away from people, animals, and buildings. The Champion TS30 unit that I have at my place costs $599 CAD, or about $499 US, and this
5:28
is about as economical as it gets for this kind of thing
5:32
My model handles 30 amps at 240 volts, which translates to 7,200 watts of total power delivered
5:40
large enough to handle the output of most generators for household backup
5:44
The unit comes with a weatherproof outlet, a power cord to connect a generator to the
5:49
port, five 120 volt 15 amp protected circuits, one 120 volt 20 amp protected circuit, and
5:57
one 120, 240 volt, 30 amp protected circuit. As generator prices decline and reliability and efficiency increases, more and more homeowners
6:08
are opting for the generator option. A manual transfer switch makes the most sense for many people, and maybe this means you too
6:16
Next time you have an outage, a few minutes' work connecting your generator to an MTS and
6:21
firing it up will get you up and running with the essential items working just like normal
