Build Your Own PORTABLE SOLAR GENERATOR - Video 3 of 6
Jan 25, 2024
Learn how to build your own portable solar generator from simple parts, and gain the knowledge you'll need to put together a much larger off-grid energy system if you choose. READ MY POPULAR ARTICLES ABOUT: Polyurethane Finish - https://bit.ly/powerbuffing DIY Hoop House Plans - https://bit.ly/hoophouseplans Submersible Pump Installation - https://bit.ly/pumpinstallation Air-Drying Wood Tips - https://bit.ly/wooddrying How to Build a Table - https://bit.ly/tablebuilding How to Stain a Deck - https://bit.ly/deckstain Choosing Waterproof Outdoor Glue - https://bit.ly/exterioradhesives How To Build A Wheelchair Ramp - https://bit.ly/wheelchairrampplans SUBSCRIBE: http://bit.ly/BLRchannel WATCH MY POPULAR VIDEO: How to Cut Perfect Miter Joints https://youtu.be/0wnjJ-Xi5FU WATCH MORE BAILEY LINE ROAD: Winter Tips - https://bit.ly/2rpnUcm
View Video Transcript
0:00
In this video, I'll show you exactly how I've helped many people experience the power of
0:05
photovoltaic energy first-hand, and the boost in self-reliance and self-confidence that this delivers
0:11
Be sure to watch this entire video, and don't forget to download the free construction plans
0:16
I'm offering. But before all this, let me recap what I've covered in my previous two videos
0:22
First, I showed you why the old method of learning about off-grid energy is a terrible
0:27
option for building energy independence. We need something better, and that's why the off-grid mastery approach is superior
0:34
to anything else I've seen so far. In my second video, I shared exactly how you can get started implementing off-grid energy
0:42
mastery for yourself. If you haven't watched these first two videos yet, do that right now
0:48
They don't take long, and I cover a lot of important points in those previous videos
0:52
You definitely don't want to miss them. Right now, I want to share something extremely practical with you
0:59
Something that has improved the lives and boosted the energy independence of many people
1:02
I've worked with over the years. And I call it the Do-It-Yourself Solar Generator Exercise
1:09
So as I said before, start by downloading the plans from the link, then get ready to
1:12
experience the power of off-grid energy in a small but useful and manageable project
1:19
Now in a minute, I'm going to take you to the shop. We're going to look right inside the solar generator
1:23
But before I do, I just want to show you what this baby can do
1:27
Now this is not the system that can power your whole house. But everything inside of it is exactly the same as what you'd put in your house except smaller
1:37
So it's a great exercise for you to learn how things work, how they go together, and
1:42
to start building confidence that you can actually make this happen for yourself
1:46
So let me plug in a few things. I'll show you a few features here, and then we'll take a look under the hood
1:50
So I built this portable solar generator primarily to provide a little bit of electric power
1:56
for my youngest daughter with her public singing, with her busking. So she can plug in her amplifier here and things like that
2:03
As I mentioned before, this is not the kind of thing that can power your whole home, but it has all of the components of a whole house system in miniature
2:11
So it's a great way of understanding how it all works to actually see the kinds of components
2:16
you're going to put together. I tried to build a lot of features into this little box
2:22
One of them here is just a light on the end for when you want a little bit of illumination
2:28
at night. This is a voltmeter here. It's very important to monitor the voltage of your battery because that affects how long
2:38
it will last. Over here, you've got a port for charging phones and anything that can plug into a USB
2:46
port can be charged there. And then this is just an accessory outlet for the kinds of things that might plug into
2:54
a vehicle. The main part of this system though is the AC output, the alternating current output
3:01
which can operate anything small that plugs into it. So for instance, here we've got a sander
3:11
It's just like a regular outlet. This unit can put out up to 1,000 watts of power
3:21
So it's not a huge amount, but I don't need a huge amount. And like I said, my aim here was small size and portability
3:29
The panel, that's a 100 watt panel. You could connect any size of panel to this
3:36
A 100 watt panel where I live, the latitude I live, on a sunny day generally puts out
3:42
maybe 70 or 80 watts of power. They never put out all that they claim to put out
3:48
And it connects to the internal workings with some cables that fit in here at the side
3:53
So when I'm moving it, I'm going to disconnect the panel to make things easier to carry
4:00
But right now, let's go inside. I'm going to open up the lid. I'm going to show you all the components that make this magic happen
4:07
One of my main aims with this solar generator was to make it as small and compact as possible
4:12
So that's why I built a box to put everything in, so there's no wasted space
4:17
I made this out of plywood mostly. You can come and take a look here
4:23
Baltic birch plywood, raised rim of quarter inch material to form a lip
4:28
Kind of, you know, if this happens to sit out in the rain a little bit, the lip's going
4:34
to stop a lot of the water from coming in. I had an artist friend of mine make up these stickers
4:40
This is the same kind of thing that you'd see on vehicles that are used for advertising
4:44
So it comes in a sheet, you peel it off, stick it on. So it makes it look nice, protects the wood a bit too
4:51
And here we have the insides. Let me start with an overview
4:56
This is the battery. This is what stores energy that is developed, generated by the photovoltaic panel, the PV panel
5:06
This is the charge controller. We can't connect a photovoltaic panel or a windmill directly to a battery because that
5:17
current, the electricity flowing in would be unregulated and it would damage the battery
5:21
So the purpose of the charge controller is to constantly monitor the state of charge
5:26
of the battery and allow the right amount of electricity in to charge that unit without
5:31
overcharging and damaging. So these two things together give us the direct current power that you saw me use when I switched
5:41
on the light here for instance or if we're charging a phone that starts with 12 volts
5:49
This is a 12 volt outlet here. So these things tap directly off the battery and they're delivering DC current
5:58
But for the plug outlet we want AC current. We actually want 120 volts AC just like you'd have in your house
6:06
We're not going to get that from the battery directly. We need to feed the power from the battery into something called an inverter and that's
6:13
what this is here. This changes 12 volts DC to 120 volts AC and provides that power to this outlet here
6:24
The inverter is the limiting factor in how much power any kind of a system like this
6:30
can put out. And this inverter is a 1000 watt unit so it can't produce any more than 1000 watts
6:37
1000 watts isn't all that much. A regular household outlet can put out maximum about 1800 watts
6:45
1200, 1500 is about the most anyone would use from one. So it's a little bit less than a regular household outlet
6:52
But remember I wanted small size and portability. So that's why I designed things this way
7:00
Why am I showing you this? Well this is a microcosm of everything that would go into an off-grid energy system for
7:08
your home. Everything except possibly the ability to connect back into the grid to sell the utility
7:16
electric power that you have generated and to get paid for that. That's something that this doesn't do
7:21
But that is something that many off-grid systems can do and it's a great thing if you've got
7:26
excess power. So this is a little exercise that you may or may not choose to do as part of the off-grid
7:36
mastery course and procedure. But it's a great way to learn and it's a great way to actually get your hands dirty, to start
7:44
stripping some wires, and when you're done you'll have something that can protect you
7:49
and your family from long-term power failures by providing a little bit of essential power
7:54
for lighting, phones, things like that. You'll also know exactly how to build a bigger version of this to power your entire house
8:01
Did you enjoy that little tour? I hope so. There's much more where that came from
8:06
In the next session of my off-grid energy school, starting soon, I'll be explaining
8:10
all my best tricks such as designing an energy system to handle the needs of an entire house
8:16
choosing specific pieces of energy hardware based on your expected needs, and how to combine
8:21
solar and wind energy for a reliable system that works better than solar or wind alone
8:28
This is going to be the best and most up-to-date training I've ever released and it contains
8:33
everything I've ever learned about off-grid energy mastery. In the next video, I'll show you that complete off-grid energy school curriculum right from
8:43
the beginning to the end. I've helped hundreds of people achieve off-grid mastery and energy independence this way
8:50
I literally draw the curtains and show you every single thing you need to learn
8:54
You don't want to miss the next video because I'll be sharing the complete game plan with
8:59
you then. So thanks for watching and stay tuned for the next video
9:03
I'll see you there
