I'm going to start with a question from David by email. He writes, since I last purchased your
0:10
Cozy Cabin course, that's one of a handful of online courses I make and sell and teach
0:15
to get me started on building my own cabin. Progress has been slow but steady. I had the
0:21
property cleared, a well drilled, graded the building area higher due to spring water issues
0:27
and installed a manual well pump. Hope to start the foundation soon. Strongly considering screw
0:33
piles. With that being said, I have another question for you. From talking to neighbours
0:40
I found out that keeping warm during the winter months is a major concern, especially on a pier
0:45
type foundation. So that would be a building raised above the ground with an open space
0:50
underneath, not enclosed or heated in any way. I have talked to some professionals about this too
0:56
and the solution seems to be that I need to have a continuous thermal barrier on top of the subfloor
1:02
and I would strongly agree with that. And then David goes on to give me a link here with the
1:07
kind of insulation he's thinking of. And then followed by another layer of subfloor on top of
1:14
the insulation and then the finished floor. What are your thoughts? Well, what David is planning
1:21
to do is actually what I teach in the course, and I like it a lot. I've never seen anyone else do
1:28
this before, but I can assure you that it works very well. If you've got a raised floor and you
1:33
want to have warm feet in the wintertime, the tendency is to stuff some fiber based bats under
1:40
there and hope for the best. That's not going to do much good. First of all, it's not going to make
1:45
much of a difference because there's all kinds of air movement through that insulation, so it's
1:50
going to be highly ineffective. Having fiber bats underneath the floor is also going to attract
1:56
mice. They love that stuff. They'll burrow in and make nests and make a terrible mess. I have seen
2:02
in time these bats fall out too, because every time you walk on the floor there's a little bit
2:07
of vibration and it shakes the bat down, and unless you have something physical to hold it in place
2:11
it's just going to fall out. So I don't like that at all, but what I much prefer is to put extruded
2:19
polystyrene foam sheets on top of the existing subfloor, and then another layer of plywood on
2:26
top. I like 5-8 inch plywood for that, with screws driven right down through the top subfloor
2:34
through the foam, through the underlying subfloor, and then about an inch and a half or so, at least
2:40
an inch and a half, into the underlying joists. So this creates a continuous barrier. Mice, squirrels
2:48
whatever, can't get into it because it's inside your house. It's not exposed underneath, and it
2:55
just works really, really well. Now, two inches would be a minimum, I should say. That's not
3:01
enough to meet code requirements for floor insulation where I live, but you can add more
3:07
to get up to the specs you need. Now, the thing to understand is, if you want warm feet in wintertime
3:15
then you're going to need more than just a well-insulated floor. In my experience, you can
3:22
have as well an insulated floor as you want, but if it's cold underneath that floor, the floor will
3:28
never be warm. Now, the floor will be a lot warmer with the foam in place, but it still wouldn't be
3:34
what you call warm. So if you want a warm floor, then an excellent option is to put some kind of
3:41
electric in-floor heating on top of everything, right underneath your finished floor. There are
3:47
some great systems out there. DITRA-HEAT, made by a company called Schluter, works really well. It's
3:53
easy to install, it's effective, it's efficient, and most of all, it's reliable. I have installed
4:00
and seen installed other electric in-floor heating systems, and it's not uncommon for other brands
4:08
to fail in time, and that's a real hassle because you have to pick up the whole finished floor to
4:13
find out what the problem is, and then replace it and put your finished floor back. The Schluter
4:18
system, never heard of anyone having any trouble with it, and it just works wonderfully well. Now
4:25
as I read David's email, I was concerned as I started to work down it for the first time
4:31
because many times, even with professionals, they'll say, oh well, you want a warm floor
4:38
you got to put some kind of skirting around that opening so you're enclosing it, and I really
4:45
disagree with that. Now, David's not going to do that, but if you're tempted to do that for yourself
4:49
let me tell you why you shouldn't. First of all, not going to make much of a difference. You can
4:54
put skirting around there, you can put insulation around the skirting to try and boost the R-value
5:01
but the fact is, there's no heat source down there in your crawl space, so you can put all the
5:07
insulation on you like, and it's only going to make marginal difference. So, first of all, it doesn't
5:12
work. It doesn't actually deliver the goods, but more importantly than that, whenever you enclose
5:17
a crawl space, especially one where there's just natural soil underneath, which is what David's
5:23
facing, then you run the very real risk of allowing humidity at certain times of the year to come up
5:32
really high, because the skirting doesn't allow ventilation, and that can lead to amazingly fast
5:38
rotting of the floor frame. I have seen two cabins, for instance, identical side-by-side, one with an
5:46
enclosed skirt around it, one without. When I looked in the enclosed skirt one, opened the door
5:52
there wasn't even any floor frame there. It had all rotted away and people just discarded it away
5:58
whereas the other one was as good as the day it was built. So, do not put on skirting. There's a
6:04
third reason too, and that's animals love to get in there when it's enclosed, and they're gonna set
6:10
up shop and give you all kinds of problems. So, David's on the right track, and so is anyone who
6:16
wants to warm up a floor. David's situation, he's building a cabin, he's following my design and my
6:23
course, that's one thing. But there are lots of homes across North America where you have a bedroom
6:29
in a space above an unheated garage. I get emails from people all the time, what can I do to warm
6:36
the floor? Well, it's the same process. Put some extruded polystyrene foam on top of whatever
6:43
floor you've got, another layer of subfloor, and then your new finished floor. That will give you
6:48
insulation, and then you add the in-floor heating, and you've got a great combination. It works very
6:54
very well. And since you're only warming the floor, you're not actually heating the space with that
7:00
in-floor electric business, then it's quite economical. If you just use it just enough to
7:06
keep your feet warmish, you're probably not even going to notice it on your electricity bill
