Everyone loves warm floors when the weather gets cold outside and I know
0:04
from personal experience that warmth coming up through your feet is a
0:08
beautiful thing. This is why in-floor heating is getting more popular all the time but the
0:13
trouble is and I know this from personal experience that actually installing in
0:18
floor heating can be troublesome especially in retrofit or renovation situations and all this is why a new and I think more reliable form of electric
0:28
in-floor heating caught my eye. It's called Dietra Heat and it's been used
0:32
successfully in Europe since 2012. It comes from the German tile accessory
0:38
manufacturer Schluter systems and if you remember they're the same people that
0:43
invented modern uncoupling membranes that improve the reliability of ceramic and porcelain tile floors. So there are three main parts to the Dietra Heat
0:53
system. A dimpled uncoupling membrane that makes the entire floor installation much more crack resistant. Electric heating cables that snap precisely into
1:03
place between the raised sections of the uncoupling membrane during on-site installation. A programmable thermostat system that monitors floor temperature
1:13
adjusting heat output to match. As you can see here the tiles sit immediately
1:19
above the heating cables for rapid and effective heat transfer. You can really
1:24
feel the heat coming up through a floor like this and it also functions without
1:28
one of the biggest risks of in-floor heating systems that I've installed in
1:33
other situations. Damaged wires and failure to heat is the biggest risk with
1:38
electric in-floor heating systems especially mat style systems. Back in 2007 it's exactly what happened with one of my own building projects. It had a
1:47
mat style system installed in the floor and less than one year after
1:51
installation it failed with no warranty support from the manufacturer at all
1:55
I've heard from a handful of homeowners over the years with the same problems
1:59
too and that's one reason why Schluter's 10-year warranty on Dietra Heat
2:04
impressed me so much. If the floor stops heating nine years 364 days after proper
2:11
installation, Schluter tells me that they will replace the whole floor, tiles, labor
2:16
and everything and make it right again. And the same warranty applies if cracked
2:21
tiles or loose grout develop too. Modern uncoupling membranes were invented back
2:26
in 1987 as a way of improving the reliability of porcelain and ceramic
2:32
tile floor installations. But they do this work in a way that's really easy to
2:36
misunderstand. While it's obvious that tiles need to be supported vertically so
2:41
that they don't flex and crack, what's less obvious is the way the installation
2:46
needs to be designed to resist horizontal movements caused by different rates of expansion between the subfloor and the tile installation itself
2:55
Uncoupling membranes allow small amounts of the side-to-side movement so the tiles
3:01
themselves and the grout stay in better shape and crack resistant. Now the Dietra
3:06
Heat uncoupling membrane works exactly the same way except it's configured to
3:12
allow the heating cables to snap right in on the top. Use modified thinset
3:17
mortar if you're installing Dietra over a wooden subfloor and unmodified thinset
3:22
if you're working over concrete. Later on you'll use unmodified to secure the
3:27
tiles to the top of the Dietra Heat membrane. Besides the ability to customize
3:32
every tile installation no matter what it is on-site, the thing that impresses me
3:37
most about the Dietra Heat system is the way the wires snap into the top of the
3:42
uncoupling membrane in a way that protects them physically while also keeping them very close to the underside of the tile so you really feel
3:49
all the warmth that's coming through. Close proximity to the underside of the
3:54
tiles gives optimal heat conduction up into your feet and when those wires snap
3:59
into place they're just below the dimples on the top of the mat so they're
4:03
unlikely to suffer any sort of damage once the wires are snapped into place
4:08
Installers are also required to electrically test the whole installation just to make sure it's working okay before the tiles go down. Care does need
4:17
to be taken when applying tile mortar with a notch trowel but like I said the
4:22
wires are protected below the surface of the membrane so the whole arrangement is
4:27
quite reliable by design. As you might expect the entire Dietra Heat system is
4:32
controlled by a programmable thermostat but in addition to preset times when
4:37
temperatures rise and fall there's also something called anticipated start. This works by bringing floor temperature up to a preset level by a certain time
4:48
instead of just switching on the heat at a certain pre-programmed time. So you
4:54
want to wake up to a full room temperature at say 630 a.m. the system
4:59
learns how much earlier than this it needs to switch on in order to get your
5:03
feet and your room warm to the level that you set at the time you set it
5:08
People living with in-floor heating systems will tell you that they feel
5:11
more comfortable at overall lower room temperatures than when heat is delivered
5:16
by forced air systems. Now I know this is true because that's what I've found
5:21
after I've installed in-floor heating at my own house. Now it's one thing to be
5:26
able to reduce room temperature by several degrees and still feel comfortable but for me the biggest benefit of in-floor heating is the way
5:34
that warmth comes right up through the floor and feels so great. It's almost
5:38
enough to make you like winter
