In this video I'm going to be introducing you to the main parts of a table saw
0:05
And all designs of saws have the same basic parts. They get their name from this top surface here, which is called the table
0:13
It can be made of cast iron, like this saw here, or aluminum, sometimes pressed steel as well
0:20
depending on the size and the cost of the tool. All table saws, of course, have a blade, which you can see here
0:28
If you take a look inside, the shaft that the blade is bolted to is called an arbor
0:36
and that arbor can be longer or shorter, depending on the model you're dealing with
0:42
Another fundamental feature is the fence. Every table saw has a fence, and it's used in rip cutting
0:51
so you can make straight cuts in relation to the blade. Miter gauge, that's here too
0:58
This is an accessory that allows you to do cross-cutting accurately, either at 90 degrees or any other angle up to about 45 degrees from the blade
1:09
We have a switch, on-off switch. The large cabinet saws like this have what's called a magnetic switch
1:16
which turns on when you press it. But if the power drops out, that saw is not going to come back on again
1:23
because the internal contactors have opened up. Simpler table saws like bench top saws that I'll introduce you to later just have a regular switch
1:33
The fence runs on rails. This is a pretty long rail set
1:39
You can get them quite a bit longer too, so you can rip wider materials
1:44
Down here, we've got the blade height adjustment wheel. Higher and lower on the blade
1:53
A similar wheel over on this side controls the angle of the blade
1:57
anywhere from about exactly 90 degrees to the table, to about 45 degrees from the table
2:04
which allows you to cut just about any sort of bevel angle you're going to run into
2:09
This saw, along with almost all other modern saws now, has a dust collection port, which I feel is pretty important
2:18
I really like dust collection. It keeps the shop neater, and it also keeps you healthier too
2:24
I'll be going into a lot more detail about all these things later
2:28
and what you need to know for proper adjustment and whatnot later, but that's the basics of a table saw
